Arayüz
|
|
Fixed WAN Port
|
1x RJ-11 for VDSL2 or ADSL2/2+
|
|
LAN/WAN Switchable Port
|
1x 10/100/1000Base-T, RJ-45 (P4)
|
|
Fixed LAN Port
|
3x 10/100/1000Base-T, RJ-45
|
|
USB Port
|
2x USB 2.0 for 3G/4G/LTE USB modem, storage, printer or thermometer
|
|
2.4G WLAN
|
802.11n 2x2 MIMO 400Mbps (ac/Vac model)
|
|
5G WLAN
|
802.11ac Wave 2 2x2 MU-MIMO 867Mbps (ac/Vac model)
|
|
FXS RJ-11
|
2 (Vac model)
|
|
Performans
|
|
Max. Throughput on VDSL
|
300 Mbps
|
|
NAT Throughput
|
600 Mbps
|
|
IPsec VPN Performance
|
200 Mbps (AES 256 bits)
|
|
SSL VPN Performance
|
80 Mbps
|
|
Max. Number of NAT Sessions
|
50,000
|
|
Max. Concurrent VPN Tunnels
|
2
|
|
VDSL/ADSL
|
|
VDSL Standards
|
ITU-T G.993.1 (VDSL), G.997.1, G.993.2 (VDSL2)
|
|
VDSL2 Profile
|
8a, 8b, 8c, 8d, 12a, 12b, 17a, 30a, 35b (not G.Fast)
|
|
VDSL Band Plan
|
997, 998
|
|
ADSL Standards
|
ANSI T1.413, ITU-T G.992.1(G.dmt), G.992.2 (G.lite)
|
|
ADSL2 Standards
|
ITU-T G.992.3, G.992.3 Annex M/J
|
|
ADSL2+ Standards
|
ITU-T G.992.5, G.992.5 Annex M/J
|
|
Internet Bağlantısı
|
|
IPv4
|
PPPoE, PPPoA, DHCP, Static IP, MPoA, PPTP/L2TP
|
|
IPv6
|
PPP, DHCPv6, Static IPv6, TSPC, AICCU, 6rd, 6in4 Static Tunnel
|
|
Multi-VLAN/PVC
|
√
|
|
WAN Failover
|
√
|
|
Connection Detection
|
ARP, Ping
|
|
WAN Data Budget
|
√
|
|
Dynamic DNS
|
√
|
|
DrayDDNS
|
√
|
|
LAN Yönetimi
|
|
VLAN
|
802.1q Tag-based, Port-based
|
|
Max. Number of VLAN
|
8
|
|
Number of LAN Subnet
|
2
|
|
DHCP Server
|
Multiple IP Subnet, Custom DHCP Options, Bind-IP-to-MAC
|
|
Wired 802.1x Authentication
|
√
|
|
Port Mirroring
|
√
|
|
Local DNS Server
|
√
|
|
Conditional DNS Forwarding
|
√
|
|
Hotspot Web Portal
|
√
|
|
Hotspot Authentication
|
Click-Through, Social Login, SMS PIN, Voucher PIN, RADIUS, External Portal Server
|
|
Ağ
|
|
Routing
|
IPv4 Static Routing, IPv6 Static Routing, Inter-VLAN Routing, RIP
|
|
Policy-based Routing
|
Protocol, IP Address, Port, Domain, Country
|
|
DNS Security (DNSSEC)
|
√
|
|
Multicast
|
IGMP Proxy, IGMP Snooping & Fast Leave, Bonjour
|
|
SMB File Sharing
|
√ (Requires external storage)
|
|
VPN
|
|
LAN-to-LAN
|
√
|
|
Teleworker-to-LAN
|
√
|
|
Protocols
|
PPTP, L2TP, IPsec, L2TP over IPsec, SSL, IKEv2, IKEv2-EAP, IPsec-XAuth, OpenVPN(Host to LAN)
|
|
User Authentication
|
Local, RADIUS, mOTP
|
|
IKE Authentication
|
Pre-Shared Key, X.509
|
|
IPsec Authentication
|
SHA-1, SHA-256, MD5
|
|
Encryption
|
MPPE, DES, 3DES, AES128, AES192, AES256
|
|
Single-Armed VPN
|
√
|
|
NAT-Traversal (NAT-T)
|
√
|
|
Güvenlik Duvarı ve İçerik Filtrelemesi
|
|
NAT
|
Port Redirection, Open Ports, Port Triggering, DMZ Host, UPnP
|
|
ALG (Application Layer Gateway)
|
SIP, RTSP, FTP, H.323
|
|
VPN Pass-Through
|
PPTP, L2TP, IPsec
|
|
IP-based Firewall Policy
|
√
|
|
Content Filtering
|
Application, URL, DNS Keyword, Web Features, Web Category* (*: subscription required)
|
|
DoS Attack Defense
|
√
|
|
Spoofing Defense
|
√
|
|
Bantgenişliği Yönetimi
|
|
IP-based Bandwidth Limit
|
√
|
|
IP-based Session Limit
|
√
|
|
QoS (Quality of Service)
|
TOS, DSCP, 802.1p, IP Address, Port, Application
|
|
VoIP Prioritization
|
√
|
|
Kablosuz LAN (wireless modeller)
|
|
Number of SSID
|
4 per radio
|
|
Security Mode
|
WEP, WPA, WPA2, Mixed(WPA+WPA2)
|
|
Authentication
|
Pre-Shared Key, 802.1X
|
|
WPS
|
PIN, PBC
|
|
WDS Repeater
|
√ (5GHz only)
|
|
Access Control
|
Access List, Client Isolation, Hide SSID, Wi-Fi Scheduling
|
|
AirTime Fairness
|
√
|
|
Band Steering
|
√
|
|
MU-MIMO
|
√ (5G Only) (dual-band model)
|
|
TxBF
|
√ (5G Only) (dual-band model)
|
|
WMM
|
√
|
|
VoIP Ağ Geçidi (V model)
|
|
Protocol
|
SIP, RTP/RTCP, ZRTP
|
|
SIP Registrars
|
6
|
|
Dial Plan
|
Phone Book, Digit Map, Call Barring, Regional
|
|
Call Features
|
Call Waiting, Call Transfer, Scheduled DND, Hotline
|
|
Voice Codec
|
G.711 A/u law, G.726, G.729 A/B
|
|
Caller ID
|
FSK_ETSI, FSK_BELLCORE, DTMF
|
|
Yönetim
|
|
Local Service
|
HTTP, HTTPS, Telnet, SSH, FTP, TR-069
|
|
Config File Export & Import
|
√
|
|
Firmware Upgrade
|
TFTP, HTTP, TR-069
|
|
2-Level Administration Privilege
|
√
|
|
Access Control
|
Access List, Brute Force Protection
|
|
Notification Alert
|
SMS, E-mail
|
|
SNMP
|
v1, v2c, v3
|
|
Syslog
|
√
|
|
Managed by VigorACS
|
√
|
|
Central AP Management
|
2 VigorAP
|
|
Fiziksel
|
|
Power Supply
|
DC 12V @ 2A
|
|
Max. Power Consumption
|
19 watts (ac model)
|
|
Dimension
|
207mm x 131mm x 42mm
|
|
Weight
|
500g (ac model)
|
|
Operating Temperature
|
0 to 45°C
|
|
Storage Temperature
|
-25 to 70°C
|
|
Operating Humidity (non-condensing)
|
10 to 90%
|
|
Certificate
|
CE, FCC
|
