Arayüzler
|
|
WAN Port
|
1x 10G/1G SFP+ Fiber Slot (P1)
1x 2.5G/1G/100M/10M Ethernet, RJ-45 (P3)
4x 1G/100M/10M Ethernet, RJ-45 (P5-8)
|
|
LAN Port
|
1x 10G/1G SFP+ Fiber Slot (P2)
1x 2.5G/1G/100M/10M Ethernet, RJ-45 (P4)
4x 1G/100M/10M Ethernet, RJ-45 (P9-12)
|
|
USB Port
|
2x USB 3.0
|
|
Console Port
|
1x RJ-45
|
|
Button
|
1x Factory Reset
|
|
Performans
|
|
NAT Throughput
|
9.4 Gbps
|
|
VPN Performance
|
3.3 Gbps
|
|
NAT Sessions
|
1,000,000
|
|
Max. Concurrent VPN Tunnels
|
500
|
|
Max. Concurrent SSL VPN
|
200
|
|
Internet Bağlantısı
|
|
IPv4
|
PPPoE, DHCP, Static IP
|
|
IPv6
|
PPP, DHCPv6, Static IPv6, TSPC, AICCU, 6rd, 6in4 Static Tunnel
|
|
802.1p/q Multi-VLAN Tagging
|
* |
|
Multi-VLAN/PVC
|
* |
|
Load Balancing
|
IP-based, Session-based
|
|
WAN Active on Demand
|
Link Failure, Traffic Threshold
|
|
Connection Detection
|
PPP, Ping, ARP
|
|
Dynamic DNS
|
* |
|
DrayDDNS
|
* |
|
LAN Yönetimi
|
|
VLAN
|
802.1q Tag-based, Port-based
|
|
Max. Number of VLAN
|
50
|
|
DHCP Server
|
Multiple IP Subnet, Custom DHCP Options, Bind-IP-to-MAC
|
|
LAN IP Alias
|
* |
|
IP Pool Count
|
Up to 1022 per LAN Subnet
|
|
PPPoE Server
|
* |
|
Local DNS Server
|
* |
|
Conditional DNS Forwarding
|
* |
|
Hotspot Web Portal
|
* |
|
Hotspot Authentication
|
Click-Through, Social Login, SMS PIN, RADIUS, External Portal Server
|
|
Ağ ve Yönlendirme
|
|
Routing
|
IPv4 Static Routing, IPv6 Static Routing, Inter-VLAN Routing, RIP v1/v2/ng, OSPFv2, BGP
|
|
Policy-based Routing
|
Protocol, IP Address, Port, Domain, Country
|
|
High Availability
|
Active-Standby, Hot-Standby
|
|
DNS Security (DNSSEC)
|
* |
|
Multicast
|
IGMP Proxy, Bonjour
|
|
Local RADIUS server
|
* |
|
SMB File Sharing
|
(Requires external storage)
|
|
VPN
|
|
LAN-to-LAN
|
* |
|
Teleworker-to-LAN
|
* |
|
Protocols
|
PPTP, L2TP, IPsec, L2TP over IPsec, SSL, GRE, IKEv2, IPsec-XAuth, OpenVPN
|
|
User Authentication
|
Local, RADIUS, LDAP, TACACS+, mOTP
|
|
IKE Authentication
|
Pre-Shared Key, X.509, XAuth, EAP
|
|
IPsec Authentication
|
SHA-1, SHA-256, MD5
|
|
Encryption
|
MPPE, DES, 3DES, AES
|
|
VPN Trunk (Redundancy)
|
Load Balancing, Failover
|
|
Single-Armed VPN
|
* |
|
NAT-Traversal (NAT-T)
|
* |
|
Ağ Güvenliği Özellikleri
|
|
NAT
|
Port Redirection, Open Ports, Port Triggering, DMZ Host, UPnP
|
|
ALG (Application Layer Gateway)
|
SIP, RTSP, FTP, H.323
|
|
VPN Pass-Through
|
PPTP, L2TP, IPsec
|
|
IP-based Firewall Policy
|
* |
|
Content Filtering
|
Application, URL, DNS Keyword, Web Features, Web Category* (*: subscription required)
|
|
DoS Attack Defense
|
* |
|
Spoofing Defense
|
* |
|
Bant Genişliği Yönetimi
|
|
IP-based Bandwidth Limit
|
* |
|
IP-based Session Limit
|
* |
|
QoS (Quality of Service)
|
TOS, DSCP, 802.1p, IP Address, Service Type
|
|
VoIP Prioritization
|
* |
|
Yönetim Özellikleri
|
|
Local Service
|
HTTP, HTTPS, Telnet, SSH, FTP, TR-069
|
|
Config File Export & Import
|
* |
|
Firmware Upgrade
|
TFTP, HTTP, TR-069
|
|
2-Level Administration Privilege
|
* |
|
Access Control
|
Access List, Brute Force Protection
|
|
Syslog
|
* |
|
Notification Alert
|
SMS, E-mail
|
|
SNMP
|
v1, v2c, v3
|
|
Fiziksel Özellikler
|
|
Rack Mountable
|
Mouting Kit Included
|
|
Dimension
|
443 mm x 285 mm x 45 mm
|
|
Weight
|
3.23 kg
|
|
Power
|
AC 100~240V, 50/60Hz
|
|
Max.Power Consumption
|
35 watts
|
|
Operating Temperature
|
0 to 45°C
|
|
Storage Temperature
|
-10 to 55°C
|
|
Operating Humidity (non-condensing)
|
10 to 90%
|
|
Certificate
|
CE ve FCC
|
