Hardware 8-port Gigabit Ethernet Ports 8 PoE/PoE+ ports (802.3af, 802.3at) with 124W PoE/PoE+ Budget Virtually AnywhereTM Easy-Mount system allows for: 1. On a Wall. 2. Under a Tabletop/Desktop. 3. On a rectangular or round pole. 4. Up in the ceiling. 5. In a standard 19-inch rack Multi-directional power cable can be routed outwards or downwards Internal power supply (simple power cord from switch to outlet) LED lights can be turned off for non-distracting placement next to a TV Performance 192KB packet buffer memory (dynamically shared across only used ports) 16 Gbps non-blocking fabric (bandwidth) 4 Priority queues Weighted Round Robin (WRR) priority queuing 4K Media Access Control (MAC) addresses with 48-bit MAC address 128 Multicast groups 64 VLANs Jumbo frames up to 9K packet size supported VLANs IEEE 802.1Q VLAN tagging Port-based VLANs (physical) Multicast IGMP snooping, v1, v2 and v3 Blocking of unknown multicast traffic Link Aggregation IEEE 802.3ad - Static LAGs 2 LAGs with max 4 members in each LAG Quality of Service (QoS) Port-based rate limiting (ingress and egress) Port-based QoS IEEE 802.1p COS IPv4 DSCP IPv4 ToS Weighted Round Robin (WRR) Network Security Broadcast, multicast, unknown unicast storm control DoS attacks prevention Reliability, Performance and Troubleshooting Port mirroring both on ingress and egress traffic Jumbo frame support Broadcast storm control Cable diagnostics Loop detection Energy Efficient Ethernet (IEEE 802.3az) compliant Broadcast, multicast, unknown unicast storm control Management Password management Web browser-based graphical user interface (GUI) for advanced configuration and management ProSAFE Plus Configuration Utility (PCU) for multi-switch management (requires Windows PC) Firmware upgrade via HTTP (Web GUI) or TFTP (Plus Utility) Config file transfers (backup, restore) using web browser-based management GUI or Plus Utility Port mirroring; many-to-one port mirroring Energy Efficient Ethernet (EEE) IEEE 802.3az (deactivated by default) Short cable power reduction Auto power-down Broadcast, multicast, unknown unicast storm control DHCP client
